Insider Brief
- Scientists at the QOT Centre for Quantum Optical Technologies and the University of Warsaw have developed a device for converting quantum information between microwave and optical photons, with potential applications in quantum network infrastructure and microwave radio-astronomy.
- The converter uses Rydberg atoms, which can interact with both microwave and optical photons, to realize the conversion at room temperature within atomic vapours inside a glass cell, showcasing a simpler design with low noise levels and better conversion parameters.
- Quantum technologies, utilizing both microwave and optical domains, have potential applications in astronomical observations, high-speed internet connections, and next-gen mobile technologies, making the microwave-to-optical conversion essential for advancing these areas.
UNIVERSITY RESEARCH NEWS — Warsaw, Poland/October 5, 2023 — A team of scientists at the QOT Centre for Quantum Optical Technologies, including a student from the Faculty of Physics (University of Warsaw), made a device capable of the conversion of quantum information between microwave and optical photons.
The results of research, published in Nature Photonics, highlight a new microwave detection method with possible applications in quantum technologies, as a part of quantum network infrastructure, and in microwave radio-astronomy.
Conversion of quantum information
Whenever you listen to a song on your phone or computer, a conversion of information happens — a file digitally encoded in your device’s memory is converted to an electric current driving your headphones. Similarly, we can convert quantum information encoded in photons — the smallest quanta of light.
For example, we can transfer information from a single microwave photon to a single optical photon. However, devices capable of single-photon operations are quite difficult to realize, because they need to be very precise and introduce very little noise. Additionally, what makes the task challenging is the fact that optical photons have energy ten thousand times larger than microwave photons and there are few media capable of simultaneously interacting with both species.
Still, the conversion of quantum information is pivotal to hybrid quantum networks — networks connecting different quantum devices, such as quantum computers. Quantum computing can be realized with microwave photons interacting with superconducting circuits, though the long-distance transfer of quantum information encoded in this manner poses a challenge due to the accumulation of noise.
However, this is no longer a problem for optical photons, which can efficiently send quantum information via optical fibers. Therefore, the microwave-to-optical converter of quantum information can be a crucial part of a quantum network adapter — an interface between quantum computers and the quantum internet.
Enlarged atoms
One known medium that can interact both with microwave and optical photons are Rydberg atoms, named after Johannes Rydberg, who researched optical spectroscopy at the turn of the 19th century and stated the famous Rydberg formula. Rydberg atoms can be produced via laser excitation of valence electrons e.g. in rubidium atoms.
This causes the atoms to increase their size a thousandfold and acquire many interesting properties, which are a hot research topic all over the scientific world. In this case, it is important to know that Rydberg atoms are very sensitive to microwave radiation.
So far, microwave-to-optical conversion has only been demonstrated in laser-cooled atoms caught in complex magneto-optical trapping setup. The scientists at the University of Warsaw are the first to show that microwave-to-optical conversion can be realized at room temperature, in atomic vapors inside a glass cell.
The proposed design of the converter is notably simpler and can be further miniaturized in the future. Additionally, the new conversion scheme shows very low noise levels and therefore can perform operations even on single photons. Even though the new converter setup is much simpler, the parameters of the conversion are surprisingly better.
In particular, the invention made at UW can work non-stop, as the atoms do not have to be prepared in a specially designed time sequence, which can take up more than 99% of the devices’ operational time in experiments done by other groups.
Using the converter device, the scientists at UW have demonstrated the detection of microwave thermal radiation at room temperature — for the first time it has been done without using microwave antennas or special low-noise amplifiers. To get to the thermal level, the device has to be sensitive to single photons, but nevertheless, the converter can work for microwave radiation a million times stronger and cannot be damaged with even stronger fields, in contrast to other standard microwave devices.
The future lies in microwaves
The rapidly developing quantum technologies use various information carriers. Quantum computers based on superconducting junctions store their information in microwave frequencies, whereas quantum memories are largely based on optical photons. Similarly to the quantum network adapter, the interconnection between the two types of devices requires an interface that can efficiently work both in microwave and optical domain. Rydberg atoms are being presented here as the solution.
Single-photon microwave operations will be important in astronomical observations researching the properties of distant bodies or the shape of the early universe via measurements of the cosmic microwave background. Until now, measurements retaining quantum information in microwave photons have not been possible and microwave-to-optical conversion may create a whole new branch of microwave radio-astronomy.
Everyday mass communication can also benefit from the discoveries in microwave detection. Next-gen mobile technologies are set to heavily utilize high-frequency microwave transmission bands, difficult to emit and detect in conventional electrical circuits. One day, atomic microwave sensors may be a crucial part of high-speed internet connection.
This is why in the Centre for Quantum Optical Technologies QOT, as well as in scientific institutes all over the world, there is ongoing research on how to employ quantum technologies in ultrasensitive microwave detection.
Featured image: Room-temperature MW-to-optical converter. a, Illustration of a warm vapor Rydberg converter: a circularly polarized MW field enters a rubidium vapor cell, where Rydberg-state atoms, excited in an interaction region defined by three laser beams, contribute to the conversion process and generate a signal beam. The arrows represent the wavevectors k of the interacting fields obeying phase-matching principles. A constant supply of ground-state atoms is ensured by the Maxwellian distribution of velocities, resulting in a continuous process without the need for atomic trapping or repumping. b, 85Rb energy-level structure employed in the conversion process. Three strong fields (probe, coupling and decoupling) are applied to the atomic medium in the near-resonant scheme. Introducing the MW field (13.9 GHz) results in a converted emission (signal) at the 776 nm transition. Optimal transduction is ensured with sign-matched σ transitions (between the states of maximal F and mF quantum numbers). c, Comparison of measured EIT and conversion in the domain of probe field detuning (δp) for resonant and 552D5/2 level-detuned cases. a.u., arbitrary units. d, The same EIT and conversion relation predicted by the numerical simulation. c,d, Red shading signifies the total conversion signal photon rate with relation to its zero background. Credit: Nature Photonics (2023). DOI: 10.1038/s41566–023–01295-w
